Description of Rockwool Insulated Roof/Wall Sandwich Rockwool SandwichPanel
Rock wool sandwich composite panel is a commonly used composite building material. The same as other types of structural insulated panels, it is also made up of two layers of structural board and one insulation core. The steel plates as outer skins offer this composite panel great strength, and the rock wool insulation material provides it with great thermal insulation.
1. Product Specifications:
Material Category: Inorganic insulation material
Combustion Performance: A
Heat Conductivity Coefficient: 0.04-0.055
Density: 80-150kg/m³
Temperature Endurance: 800ºC
Water Absorption:≤2%
ROCKWOOL Sandwich Composite Panel
| Brand of steel plates: | Bao Steel, Yieh Phui Steel, Ma Steel, BHP Steel. |
| Painting of steel plates: | PVDF, SMP, HDP, PE; The top painting should be above 25μm. |
| Galvanized layer of steel plates: | Exterior plate:55% Aluzinc above 100g/m³ or Zinc coating above 150g/m³; Inner plate:55% Aluzinc above 70g/m³ or Zinc coating above 100g/m³. |
| Thickness of steel plates: | 0.4mm-0.7mm. |
| Thickness of core: | 50mm/75mm/100mm/120mm/150mm. |
|
|
|
| Density of core: | 80-150kg/m³ |
| Effective width: | 950mm/1150mm |
| Panel Length: | According to customers' request |
